Hirayama HICLAVE
HV-Ⅱ Series Autoclaves

Features

AUTOCLAVES CLASS B

Safety valve, Pressure protection system, temperature
protector of chamber walls.
Suitable for sterilization of liquids.
LCD display.
type class B.
volume: 8-25 litres.

USB port

Internal Memory

Complies with European type B standard.

These Autoclaves are common in:

Vacuum autoclaves are common in dentists who perform gum surgery and dental implants, In clinics that perform surgeries in the field of aesthetics
And beauty salons that perform pedicures and medical manicures
And in the field of nail care.

High-quality and professional autoclaves for dental and aesthetic clinics

Specifications

Model HV-25L HV-50L HV-85L HV-110L
Effective capacity 25 L 50 L 85 L 110 L
Chamber size (φ ｘ Ｈ ｍｍ) 240 x 550 300 x 710 420 x 615 420 x 795
Temperature setting range Sterilization 105℃ - 126℃ Variable 105℃ - 135℃ Variable 105℃ - 128℃ Variable 105℃ - 123℃ Variable
Maximum working pressure 0.17Mpa 0.26Mpa 0.18Mpa 0.16Mpa
Thermometer 5℃ - 128℃ 5℃ - 137℃ 5℃ - 130℃ 5℃ - 125℃
Pressure gauge 0MPa - 0.4MPa
Outside dimensions (W x D x H mm) 485 x 470 x 956 547 x 532 x 1046 667 x 652 x 1011 667 x 652 x 1191
Weight (Approximately) 41 kg 57 kg 71 kg 81 kg
Required power supply facility 1.5kW 2.0kW 3.0kW 4.0kW
Operation mode 4 modes (LIQUID with warming, LIQUID without warming, SOLID, DISSOLUTION), one memory for each mode
Temperature setting range Dissolution 60℃ - 100℃ Variable
Temperature setting range Warning 45℃ - 60℃ Variable
Time setting range Sterilization 1 min - 250 min, Remaining time is displayed
Time setting range Dissolution 1 min - 60 min, Remaining time is displayed
Time setting range Warning 20 h, fixed
Time setting range Auto-Start Program autoclave to start 1 min to 1 week later
Exhaust setting 0% - 100%, Valve opening degree setting for LIQUID mode
Safety devices Pressure safety valve, Over-current and earth leakage breaker, Low water cut off device
Alarms, error display Low water heating, Temperature sensor wire disconnection, Over-temperature, Over-cool, Over-pressure, Abnormality in lid opening / closing lever lock
Pressure vessel category Small sized pressure vessel
Chamber material Stainless steel (SUS304)
Power supply AC230V / 240V, 50Hz / 60Hz (Single phase) (Specify voltage when ordering.)
Power connection Ring terminal
Supplied accessories Wire mesh basket (2), Bottom plate, Drainage hose, Exhaust hose, Exhaust bottle, Drain bottle, Caster stopper (2)

Accessories

  • NONE
